AFL3-W19C-ULT3-i5/PC/4G-R10 18,5" PC

IEI/i5-6300U/4GB/PCTouch

Product nr: 121674
118168
Datablad
Spec ItemDescription
Communication
BluetoothBluetooth v4.0 (M.2 slot)
WirelessIEEE 802.11a/b/g/n/ac
Environment
Humidity10% to 95% (non-condensing)
IP LevelIP 64 compliant front panel
Operating Temperature-20°C~50°C
Safety & EMCCE / FCC
Storage Temperature-20°C~60°C
I/O Interface
AudioAMP 3W + 3W (internal speaker)
Audio CodecALC892
Ethernet2 x Intel® I211-AT PCIe GbE controller
I/O Ports and Switches1 x RS-232 by DB-9 (RI/5V/12V)
1 x RS-232/422/485 by DB-9 (RI/5V/12V)
2 x GbE LAN
4 x USB 3.0
1 x HDMI output
1 x Power switch
1 x Reset button
1 x AT/ATX switch
1 x 9-30V lockable power jack
RAMTwo 260-pin DDR4 SO-DIMMs (system max.32GB)
LCD
Backlight MTBF30,000 (LED backlight panel)
Brightness (cd/m2)250
Contrast Ratio1000:1
LCD Color262K
Pixel Pitch (mm)0.240 (H) x 0.240 (V)
Resolution1366 x 768 (16:9)
Size18.5""
Viewing Angle (H-V)170º/160º
Other Features
Camera2-megapixel with low light function
Microphonedigital microphone
OSD FunctionSoftware OSD
System CoolingFanless
Physical Characteristics
ColorBlack C
Construction Front PanelPC + ABS Plastic
Cutout Dimensions443 x 261 (W x H) (mm)
Dimensions (LxWxH) (mm)470 x 290 x 70
MountingPanel, Wall, Rack, Stand and Arm
VESA 75mm x 75mm / 100mm x 100mm
Net Weight7.3Kg
Power
Power consumption12V@7.1A
Power Requirement9 V ~ 30 VDC
System
Cooling method / System FanFanless
CPUIntel® Core™ i5 and Celeron® ULT Processor
Storage1 x 2.5” SATA 3Gb/s HDD bay
1 x M.2 M key PCIe storage (2280 or 22110)
1 x mSATA slot
Touch
Touch ControllerEETI EXC3180
Touch ScreenProjected capacitive type with USB interface
Weight
Weight7.3/10Kg
I/O Interface
I/O Interface1 x HDMI(output)
4 x USB 3.0
1 x Power In(9-30V lockable power jack)
1 x RS-232(DB-9 (RI/5V/12V))
2 x LAN(Gbe)
1 x Reset Button
1 x Power Switch
1 x AT/ATX switch
1 x RS-422/485(DB-9 (RI/5V/12V))
