Spec Item

Description

Dimensions

233 x 175 x 50

Humidity

10% to 95% (non-condensing)

Operating Temperature

-10°C~50°C

Safety & EMC

CE/FCC

Storage Temperature

-20°C~60°C

Audio

ALC892

Ethernet

2 x PCIe GbE by RTL8111E controller

Brightness (cd/m2)

450

Contrast Ratio

600:1

LCD Color

16.2M

Pixel Pitch (mm)

0.213 (H) x 0.213 (V)

Resolution

800 x 600 (4:3)

Size

8.4"

Viewing Angle (H-V)

160º / 140º

Power consumption

12V@2A(Intel® J1900 CPU with 2GB 1333 MHz DDR3L memory)

Power Requirement

9 V ~ 30 V

CPU

Intel® Celeron® J1900 (quad core, 2.0 GHz)

Memory Max.

One 204-pin 2 GB 1333MHz single-channel, 2GB
DDR3L SDRAM pre-installed (system max. 8GB)

Storage

mSATA

Touch Controller

 EXC3160

Touch Screen

Projected capacitive type

Weight

0.8/2.44

I/O Interface

1 x Reset Button

1 x Power Switch

1 x AT/ATX switch

1 x DC Input Jack(9-30V Lockable)

1 x LAN(Gbe)

2 x USB 3.0

2 x USB 2.0

1 x Audio((line-out))

1 x RS-232((RJ45 connector))

1 x RS-422/485((DB-9 connector))
