Hikvision DS-PDMCS-EG2-WE(B)

The Hikvision DS-PDMCS-EG2-WE(B) is a wireless slim magnetic contact detector designed for the AX PRO alarm system. It provides discreet and reliable detection of door or window openings, making it ideal for indoor perimeter protection. With secure two-way communication, tamper protection, and a compact design, it ensures dependable performance in residential and commercial environments.

Key Features

• Opening Detection: Magnetic contact sensor with a maximum detection gap of 52 mm.
• Slim Design: Ultra-compact and unobtrusive, ideal for window frames and tight spaces.
• Secure Communication: Tri-X two-way RF protocol with AES-128 encryption and frequency hopping.
• Remote Configuration: Fully configurable via mobile app.
• LED Indicator: Blue LED for alarm status indication.
• Easy Installation: Multiple enrollment methods including power-up, remote ID, and QR code.
• Battery Life: Up to 3 years with a CR2450 battery.
• Tamper Protection: Front and rear tamper-proof design.

Specifications

• Detection Method: Opening contact
• Detection Gap: Up to 52 mm
• Transmission Frequency: 868 MHz
• Transmission Range: Up to 1 km (open area)
• Transmission Security: AES-128 encryption
• Battery Type: CR2450 × 1
• Battery Life: Up to 3 years (standby)
• Operating Temperature: -10 °C to 55 °C
• Humidity: 10% to 90% RH (non-condensing)
• Dimensions (Main Unit): 29 mm × 69 mm × 10 mm
• Dimensions (Magnet): 14 mm × 69 mm × 10 mm
• Weight: 38 g
• Mounting Method: Wall-mount (wooden surfaces only)
• Color: Black

Part of the AX PRO wireless intrusion alarm system, the DS-PDMCS-EG2-WE(B) offers discreet and effective perimeter protection, ensuring secure and responsive monitoring of entry points with minimal visual impact.
