Hikvision DS-K1T502DBWX-CQR

The Hikvision DS-K1T502DBWX-CQR is a robust and versatile access control terminal that integrates card reading, PIN, and QR code authentication in a single device. Designed for both security and convenience, it supports intercom functionality, remote management via the Hik-Connect app, and multiple communication protocols. With IP65 and IK09 protection, it is ideal for demanding indoor and outdoor environments.

Key Features

• Multi-Authentication: Supports M1, DESfire, Felica cards, PIN codes, and dynamic QR code authentication.
• Video Intercom: Built-in 2 MP camera with H.264/H.265 compression and SIP protocol support.
• Remote Management: Fully manageable via the Hik-Connect mobile app.
• Durable Design: IP65 and IK09 rated with zinc alloy housing for enhanced durability.
• Flexible Connectivity: Supports wired Ethernet, Wi-Fi (2.4 GHz), Bluetooth, RS-485, and Wiegand output.
• Storage Capacity: Supports up to 100,000 cards and 300,000 events.
• Audio Support: Two-way audio communication with built-in microphone and speaker.
• Expandable Storage: Supports up to 256 GB SD card (optional).

Specifications

• Camera: 2 MP, HFOV: 110°, VFOV: 81°, DFOV: 122°
• Video Compression: H.264, H.265
• Network: 10/100 Mbps Ethernet, Wi-Fi (802.11b/g/n), Bluetooth
• Interfaces: RJ-45, RS-485, Wiegand, SD card slot, lock control, exit button, door contact, alarm input/output, tamper
• Authentication Methods: Card (M1, DESfire, Felica), PIN, QR code
• Power Supply: 12–24 VDC, 1 A
• Power Consumption: = 12 W
• Operating Temperature: -40 °C to 70 °C
• Protection Level: IP65, IK09
• Languages Supported: Multilingual (including English, French, Spanish, German, Russian, and more)

The DS-K1T502DBWX-CQR is part of Hikvision’s Pro Series access control solutions, offering advanced security, flexible integration, and user-friendly operation for modern access management systems.
