DS-K1105EDB Pro Card Reader

The Hikvision DS-K1105EDB is a high-performance access control reader designed for secure and flexible authentication. With support for multiple protocols and card types, it ensures seamless integration into modern access control systems.

Key Features

• Supports RS-485, Wiegand (W26/W34), and OSDP protocols
• Built-in M1 and EM card reading module (13.56 MHz & 125 KHz)
• Supports Desfire card reading
• Integrated buzzer for reading status indication
• Supports online firmware upgrade
• Multiple authentication methods: card swiping, Bluetooth, etc.
• Touch panel operation
• Occlusion detection and Bluetooth-enabled gesture-based door opening

Specifications

• Interface: RS-485, Wiegand
• Card Types: EM card, M1 card, DESfire card
• Power Supply: DC 12V
• Power Consumption: =6W
• Working Temperature: -40°C to +65°C
• Working Humidity: 0% to 90%
• Protection Level: IP66
• Dimensions: 139 × 46 × 21.2 mm (5.47 × 1.81 × 0.83 inch)
• Installation: Wall mounting
• Weight: 167.7g
• Buzzer: Supported
