Moxa RKS-G4028-L3-4GT-HV-T

The Moxa RKS-G4028-L3-4GT-HV-T is a modular Layer-3 managed Ethernet switch for rugged industrial use. It features 4 Gigabit RJ45 ports, three module slots for interface extensions, one isolated high-voltage power supply (110/220 VAC or VDC), and operates in extreme environments from -40 C to 75 C.

Key Features

• 4 × 10/100/1000BaseT(X) RJ45 ports
• 3 module slots for optional Ethernet interface modules (e.g. copper, fiber, Fast Ethernet, etc.)
• Layer-3 switching functionality
• Isolated power input: 110/220 VAC or VDC
• Alarm contact: 1 relay output (2 A @ 24 VDC)
• Operating temperature: -40 C to 75 C
• Extended voltage input range: approx 88-300 VDC or 85-264 VAC depending on model
• IP30 rackmount enclosure
• Weight: approx 4900 g; Dimensions: ~440 × 44 × 296 mm
