Moxa TN-4524A-16PoE-WV-T

The Moxa TN-4524A-16PoE-WV-T is an EN 50155 certified PoE Ethernet switch designed for railway and industrial environments. It features 16 Fast Ethernet PoE+ ports, 8 additional Fast Ethernet non-PoE ports, dual wide-voltage 24-110 VDC power input, and operates in harsh conditions from -40 C to 75 C.

Key Features

• 16 × 10/100BaseT(X) PoE+ ports with M12 D-coded connectors
• 8 × 10/100BaseT(X) non-PoE ports with M12 D-coded connectors
• Dual input power supply: 24-110 VDC
• Alarm contact: 2 relay outputs via M12 A-coded 5-pin male connector, 1 A @ 30 VDC
• Total PoE power budget: 120 W
• Operating temperature range: -40 C to 75 C
• Metal housing; wall mounting; IP42 rating
• Dimensions: 347.8 × 132 × 122.3 mm; Weight: approx 2,388 g
