Moxa TN-4528A-16PoE-2GPoE-2GODC-WV-CT-T

The Moxa TN-4528A-16PoE-2GPoE-2GODC-WV-CT-T is an EN 50155 certified managed Ethernet switch designed for railway and industrial environments. It includes 16 Fast Ethernet PoE+ ports, 8 additional non-PoE Fast Ethernet ports, 2 Gigabit PoE+ ports, and 2 1000BaseLSX fiber optic ports with Q-ODC connector. It supports dual wide-voltage DC power input (24-110 VDC), operates from -40 C to 75 C, has conformal coating, and is housed in a metal IP42 enclosure.

Key Features

• 16 × 10/100BaseT(X) PoE+ ports with M12 D-coded connectors
• 8 × 10/100BaseT(X) non-PoE ports with M12 D-coded connectors
• 2 × 100/1000BaseT(X) PoE+ ports with M12 X-coded connectors
• 2 × 1000BaseLSX fiber ports via Q-ODC fiber connector
• Total PoE power budget: 120 W
• Input voltage: 24-110 VDC, 2 power inputs, overload and reverse polarity protection
• Operating temperature: -40 C to 75 C
• Housing: Metal body; IP42; conformal coating (CT version)
• Size: 347.8 × 132 × 122.3 mm; Weight: approx 2,645 g
