Moxa UC-8132-LX

The Moxa UC-8132-LX is a compact, Arm-based industrial computer designed for embedded data acquisition applications. It features an Armv7 Cortex-A8 300 MHz processor, 256 MB DDR3 RAM, and 8 GB eMMC storage, with an additional SD card slot for expansion. The device operates within a temperature range of -10°C to 60°C, making it suitable for various industrial environments.

Key Features

• Processor: Armv7 Cortex-A8 300 MHz
• Memory: 256 MB DDR3
• Storage: 8 GB eMMC, with an SD card slot for additional storage
• Operating System: Moxa Industrial Linux 1 (Debian 9, kernel 4.4), supported until 2027
• Ethernet Ports: 2 x Auto-sensing 10/100 Mbps (RJ45)
• Serial Ports: 2 x RS-232/422/485 (software-selectable)
• USB Ports: 1 x USB 2.0 Type-A
• Expansion Slot: 1 x mini PCIe (supports cellular modules)
• SIM Slot: 1 x Mini SIM slot
• Console Port: 1 x RS-232 (TxD, RxD, GND), 4-pin header output
• Reset Button: Yes
• Magnetic Isolation Protection: 1.5 kV built-in for Ethernet ports
• Baud Rate: 300 bps to 921.6 kbps
• Data Bits: 5, 6, 7, 8
• Stop Bits: 1, 1.5, 2
• Parity: None, Even, Odd, Space, Mark
• Flow Control: RTS/CTS, XON/XOFF, ADDC (RS-485), RTS Toggle (RS-232)
