| Hardware Specifications |
| Hardware Version | 2 |
| Copper Ports | 8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports |
| SFP/mini-GBIC Slots | 2 1000Base-SX/LX/BX SFP interfaces (Port-9 and Port-10)
Compatible with 100Base-FX SFP
|
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 20Gbps / non-blocking |
| Throughput (packet per second) | 14.8Mpps |
| Address Table | 8K entries, automatic source address learning and ageing |
| Share data Buffer | 512 kilobytes |
| Flow Control | IEEE 802.3x pause frame for full-duplex. Back pressure for half-duplex |
| Jumbo Frame | 9Kbytes |
| Reset Button | < 5 sec: System reboot
> 5 sec: Factory Default
|
| ESD Protection | 6KV DC |
| EFT Protection | 6KV DC |
| Enclosure | IP30 aluminum metal case |
| Installation | DIN rail kit and wall mount kit |
| Alarm | One relay output for power failure.
Alarm relay current carry ability: 1A @ DC 24V
|
| LED Indicator | System: | Power 1 (Green) | | Power 2 (Green) | | Fault Alarm (Green) | | Ring (Green) | | R.O. (Green) |
Per 10/100/1000T RJ-45 Ports: | Power LNK/ACT (Green) | | 1000 (Orange) |
Per SFP Interface: | LNK/ACT (Green) | | 1000 (Orange) |
|
| Dimensions (W x D x H) | 87.8 x 135 x 56 mm |
| Weight | 720g |
| Power Requirements | DC 12 to 48V. AC 24V power adapter |
| Power Consumption | 10 watts / 34BTU (full loading) |
| Layer 2 function |
| Basic Management Interfaces | Web Browser, Remote Telnet, SNMP v1, v2c |
| Secure Management Interface | SSH, SSL, SNMP v3 |
| Port configuration | Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Power saving mode control
|
| Port Status | Display each port’s speed duplex mode, link status, flow control status. Auto negotiation status, trunk status. |
| Port Mirroring | TX / RX / Both
Many to 1 monitor
|
| VLAN | 802.1Q Tagged based VLAN ,up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs
|
| Link Aggregation | IEEE 802.3ad LACP / Static Trunk
Support 5 groups of 10-Port trunk support
|
| QoS | Traffic classification based, Strict priority and WRR
8-level priority for switching
- Port Number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/TOS field in IP Packet
|
| IGMP Snooping | IGMP (v1/v2/V3) Snooping, up to 255 multicast Groups
IGMP Querier mode support
|
| MLD Snooping | MLD (v1/v2) Snooping, up to 255 multicast Groups
MLD Querier mode support
|
| Access Control List | IP-Based ACL / MAC-Based ACL
Up to 123 entries
|
| Bandwidth Control | Per port bandwidth control
Ingress: 500Kb~80Mbps
Egress: 64Kb~80Mbps
|
| SNMP MIBs | RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2819 RMON MIB (Group 1, 2, 3 and 9)
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
RFC-2933 IGMP-STD-MIB
RFC3411 SNMP-Frameworks-MIB
IEEE 802.1X PAE
LLDP
MAU-MIB
|
| Standards Conformance |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Stability Testing | IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
| Standards Compliance | IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX / 100Base-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP version 1
RFC 2236 IGMP version 2
RFC 3376 IGMP version 3
RFC 2710 MLD version 1
FRC 3810 MLD version 2
|
| Environment |
| Operating | Temperature: -40 ~ 75 degrees C
Relative Humidity: 5 ~ 95% (Non-condensing)
|
| Storage | Temperature: -40 ~ 75 degrees C
Relative Humidity: 5 ~ 95% (non-condensing |
