Physical Port

• One 10/100/1000BASE-T with IEEE 802.3bt++ Gigabit RJ45 port
• 1 SFP port, supporting 100/100BASE-X transceiver dual mode

Power over Ethernet

• Complies with IEEE 802.3bt PoE++ Type-4  PSE
• Compatible with IEEE 802.3at/af PoE+ standard
• 1 IEEE 802.3 bt/at/af device powered
• Supports PoE Power up to 95 watts for PoE port
• Provides DC 54V power over RJ45 Ethernet cable to PD with Ethernet port
• Auto detects IEEE 802.3bt/at/af equipment and protects devices from being damaged by incorrect installation
• Remote power feeding up to 100m
• Auto detects powered device (PD)

Layer 2 Features

• Supports auto-negotiation and 10/100Mbps half / full duplex and 1000Mbps full
  duplex mode on RJ45 port
• Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame
  flow control (full-duplex)

Hardware

• LED Indicators
  • System: Power 1, Power 2, Alarm and PoE usage
  • Fiber port: LNK/ACT
  • 10/100/1000BASE-T port: LNK/ACT, PoE-in-use
• DIP switch 1: LFPP (Link Fault Passthrough PoE Control) On/Off
• DIP switch 2: PoE (Legacy / BT) mode selection

Industrial Case and Installation

• IP30 metal case
• DIN-rail, wall-mount or side wall-mount design for redundant power design
• 12 ~ 54V DC redundant power with reverse polarity protection and connective
  removable terminal block for master and slave power
• Supports 6000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
