Physical Port

• 16 10/100/1000BASE-T RJ45 ports with auto MDI/MDI-X function
• 2 SFP interfaces, supporting 1000BASE-X SFP transceiver

Layer 2 Features

• Supports auto-negotiation and 10/100/1000Mbps half/full duplex mode
• Prevents packet loss with back pressure (half-duplex) and
  IEEE 802.3x pause frame flow control (full-duplex)
• Complies with IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.1p CoS
• Supports 8K MAC address
• Automatic address learning and address aging

Industrial Case and Installation

• IP30 metal case
• DIN-rail and wall-mount designs
• 12 to 48V DC, redundant power with reverse polarity protection
• 24V AC power input
• Supports 6000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
• Free fall, shock-proof and vibration-proof for industries
