Physical Port

• 2-port 10/100/1000BASE-T RJ45 with IEEE 802.3at PoE+ injector function
• Two SFP slots, supporting 1000BASE-X and 100BASE-FX transceiver dual mode

Power over Ethernet

• Complies with IEEE 802.3at PoE Plus end-span PSE.
• 2 IEEE 802.3at/af device powered
• Supports PoE Power up to 30 watts for PoE port.
• Provides DC 48~54V power over RJ45 Ethernet cable to PD with Ethernet port.
• Auto detects IEEE 802.3at/af equipment and protects devices from being
  damaged by incorrect installation.
• Remote power feeding up to 100m
• IEEE 802.3at/af PoE splitter devices compatible

Layer 2 Features

• Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps
  full duplex mode on RJ45 port.
• Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause
  frame flow control (full-duplex).
• PROFINET Traffic Pass-through with QoS

Industrial Case and Installation

• IP30 metal case
• DIN-rail and wall-mount designs
• 48V~54V DC power with reverse polarity protection
• Connective removable terminal block
• Supports 6000 VDC Ethernet ESD protection.
• -40 to 75 degrees C operating temperature
• Free fall, shock-proof and vibration-proof for industries
