Cellular Interface
Number of ports 4 or 2 connectors optional (MAIN + AUX + ANT1 + ANT2)
Connector M16, female

Wi-Fi Interface
Number of ports 2 (WiFi MAIN + WiFi AUX)
Connector M16, female

Ethernet Interface
Number of ports 5, 2 or 1 ports optional
 10/100 Mbps, ETH0~ETH4
Connector M12

Serial Port
Number of ports 1 x RS-232, 1 x RS-485 or 1 x RS-232 +
 1 x RS-485
Connector M12, at least 7 PIN
 (TXD, RXD, CTS, RTS, GND, A, B)

Power Supply
Number of ports 1 x POWER + 1 x POWER OPTIONAL
Connector M12, at least 3 PIN (DC+, DC-, GND)
Input voltage POWER port -
 100 - 240 V, 50-60 HZ AC input
 9 - 60 V DC input
 (9 - 36 V DC for R2000 Ent)
 POWER OPTIONAL -
 15 - 18 V for new energy input
 48 - 57 V for POE input

Physical Characteristics
Enclosure cover Fully detachable
Weight 1010 g
Dimensions 310 x 245 x 95 mm
Installations Wall mounting and pole mounting
