Hikvision DS-PDPC12PF-EG2-WE(B)/BLACK
The Hikvision DS-PDPC12PF-EG2-WE(B)/BLACK is a wireless PIR camera detector designed for the AX PRO alarm system. It combines passive infrared detection with video verification, offering 24/7 full-color imaging and advanced digital signal processing. With pet immunity, tamper protection, and long battery life, it ensures reliable indoor intrusion detection and visual confirmation.
Key Features
- Dual Detection: Passive infrared and video verification for accurate alarm triggering.
- 24/7 Color Imaging: Full-color video capture even in low-light conditions with white light fill.
- Pet Immunity: Immune to pets up to 30 kg to reduce false alarms.
- Smart Environmental Control: Advanced digital signal processing and 3D optics for stable performance.
- Wireless Communication: CAM-X two-way RF protocol with AES-128 encryption.
- Remote Configuration: Fully configurable via mobile app.
- Easy Installation: Multiple enrollment methods and wall-mount design.
- Long Battery Life: Up to 6 years with CR123A × 3 batteries.
Specifications
- Detection Range: 12 m
- Detection Angle: 85.9°
- Detection Zones: 52
- Detectable Speed: 0.3 to 2 m/s
- Sensitivity: Auto, High, Pet
- White Light Filter: 6500 lux
- Video Resolution: 640×480, 320×240, 160×120 (JPEG)
- Field of View: 88.4° (H), 54.0° (V)
- Fill Light: White light, 12 m range
- Transmission Frequency: 868 MHz
- Transmission Range: Up to 800 m (open area)
- Tamper Protection: Front and rear
- Operating Temperature: -10 °C to 55 °C
- Humidity: 10% to 90% RH (non-condensing)
- Dimensions: 72.2 mm × 120.5 mm × 56.7 mm
- Weight: 220 g
- Battery Type: CR123A × 3
- Battery Life: Up to 6 years
- Mounting Height: 1.8 to 2.4 m
- Mounting Method: Wall
- Color: Black
Part of the AX PRO wireless intrusion alarm system, the DS-PDPC12PF-EG2-WE(B)/BLACK offers intelligent detection and real-time visual verification, enhancing indoor security with precision and clarity.
